OsmaDrain 87.5° Double Socket Unequal Junction 160mm Brown

IDPO6D219Z Drainage > House Drain EN1401 > Osma & Polypipe > OsmaDrain 87.5° Double Socket Unequal Junction 160mm Brown

Pricing available upon sign in

Alternatively, contact a branch to order

Please log in/register  to save items.

Product information

The OsmaDrain Double Socket Unequal Junction 87.5° 160mm Dia Brown is designed with stiffness class of SN8. The product is manufactured from uPVC and is used for drainage applications with depth of 10m. The product is easy to demount. The junction is supplied with sockets on all ends. The sockets are fitted with ring seals, which acts as both a sealing and expansion joint. The pipe installation is done by cutting it cleanly, at right angles to its axis and then fitting at one end through push fit system. It is made with cut out marks to convert to a channel bend for use within traditional manholes. Making it suitable for use in gravity drainage and sewer installations.

Features & benefits
  • Recyclable
  • Corrosion resistant
Product Name OsmaDrain 87.5° Double Socket Unequal Junction 160mm Brown
Brand Osma
Manufacturer Name Wavin
Manufacturer Part Number 6D219
EAN 5011479108932
Compliance Approvals BS EN 13476
Warranty Period 12  months
Materials PVC-U
Commercial Or Domestic Use Both
Range Double Socket Junction
Model Number 6D219
Colour Golden brown
Application Heating & plumbing, internal/external
Pack Quantity 1
Country Of Origin United Kingdom
Applicable Standards ISO 9001
Finish Smooth
Recyclable Yes
Renewable No
Product Width 190  mm
Product Weight 2.1  kg
Product Height 326  mm
Product Length 443  mm
Diameter 160  mm
Moisture Resistant Yes
Angle 87.5  degrees
